Painting Blocks to Paint Blocks

Painting blocks to use in light and color-study still-life as explained in this previous post. (Newly gessoed panels drying in little rack behind the blocks).

After jumping head first (or was it feet first?) into oil painting, and then flailing about, trying to find my way, I realized it was time to go back to basics. Just as with writing or speaking, a basic vocabulary is essential to expressing oneself.

But I was trying speak “oils” using the vocabulary of color I’d learned with watercolor, assuming that Red is Red, whether it’s watercolor or oils. Unfortunately, I’m finding that’s like assuming if you can speak English you can speak French since they use the same alphabet.

Testing Colors to Choose a Palette

Oil painting tests of different brands of color to choose my basic palette
(Click Images To Enlarge)

When I first started painting with watercolor, I made dozens of color charts, testing the various pigments to learn about their natures, alone and mixed with other colors. In watercolor this is really essential since there are so many characteristics that affect the flow of the paint: whether it charges into neighboring paint or resists it; whether it’s opaque or transparent; sedimentary (leaving little spots of sediment), staining or lifts easily, how it mixes with other colors and more.

I hadn’t done this with oil painting. But watching Camille Przedowek demonstrate a couple of weeks ago, I was struck by her huge “vocabulary” of color. She was quickly mixing up and painting with colors I couldn’t even name! I realized my oil painting color vocabulary is about that of a 4-year old from a foreign country.

(CLICK “Continue Reading” to read and see the rest…)

Camille recommended making color charts, using the colors from my palette, mixing each of them with each other (more explanation at the end below). But before I could do that I needed to narrow the selection of colors and brands on my standard palette to speed up charting and learning the mixing qualities of the colors.

Camille suggested a list of Winsor & Newton colors. I’d been using mostly Gamblin paints. To decide which colors to keep on my palette I made some charts to compare the different colors and brands. I was surprised at the extent of some of the differences.

For one thing, the actual pigments used by different paint companies for the identically-named colors are often different. I know from my watercolor experience that pigments matter so I always look at which pigments paints are made from. Pigments are specified on the tubes with both their chemical names and their pigment index numbers (e.g. “Quinacdridone Violet”= PV 19 (Pigment Violet 19).

Alizarins and Siennas Testing Alizarin with Viridian

Alizarin Crimson & Burnt Sienna tests

Click on the color charts above and you’ll see a good example of these differences. The two colors at the top left of the first chart are both called Permanent Alizarin, substitutes for true Alizarin Crimson which is not a permanent color and is rarely used anymore. I added white in increasing amounts going down each column.

The square on the left is Winsor & Newton’s Permanent Alizarin Crimson, made from Anthroquinine, whose chemical name is Pigment Red 177 (or PR 177). You can see how bright and vibrant a color it is. On its right is Gamblin’s version, Alizarin Permanent, made from Quinacridone Red B, Perylene Red, and Ultramarine Blue (Pigment Violet 19, Pigment Red 149, Pigment Blue 29).

Gamblin was trying make a color as much like the original Alizarin as possible, but with all those different pigments it seems much duller when blended with white or with Viridian, as in the next chart on the right above. On that chart I mixed Viridian equally with those two Alizarins and then added white to those mixtures.

The same seems to be true of the Burnt Siennas by Winsor & Newton and Gamblin in the middle of the top left chart. Winsor Newton uses Synthetic Iron Oxide, PR 101. It’s bright and transparent. Gamblin uses Calcined Natural Iron Oxide, Pigment Brown 7) which is semi-transparent and a much duller color.

On the charts below I compared Yellow Ochres and other earth colors. I compared similar blues (many with misleading names, such as Manganese Blue which is actually Phthalocyanine blue mixed with white since Manganese Blue paint is no longer made (due to the high toxicity involved in the manufacturing process.) Except for the the more expensive, single pigment Cerulean, all of the blues in the chart are actually made from Phthalo blue dolled up to look like Cerulean or the non-existent Manganese.

Ochre test Testing Blues Testing Greens

The greens above are all manufactured from a combination of yellow and blue pigments except for Viridian which is a single pigment, low intensity, transparent green.

I’ve narrowed down my pigment choices, switching to some of the Winsor Newton colors from Gamblin and now I’m starting to working on the actual color combining charts. I’ve already had some really exciting “Aha!” moments seeing the surprising things that some colors do when mixed together.

I’m hoping that once I’m more fluent in the color language of oils I can get back to expressing myself in actual paintings without so much stuttering and stumbling and blurting of wrong “words.”
